Gothic architecture in France, England, and Italy (1915)
Jackson, Thomas Graham, Sir, 1835-1924 · Cambridge [Eng.] University Press · leaf 50
CII. ii] THE GOTHIC VAULT 23 … 24 THE GOTHIC VAULT [CH. II The groin-ing line Let US take first an example of a cross-vault overa square bay of moderate size, say that of the crypt atWinchester which is about I4xi4. The four equalbounding arches are represented by A, B, C, D in Fig. 4,of which one A, E, B is set up in elevation…
Architecture, Gothic
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
