Gothic architecture in France, England, and Italy (1915)
Jackson, Thomas Graham, Sir, 1835-1924 · Cambridge [Eng.] University Press · leaf 73
wards the centre of the mainvault where the various ribs met. In Fig. 13 AD andBC are the transverse arches dividing the bays, andAC and BD are the diagonals: EF is the intrudedtransverse arch, G the common point of intersection, and 42 THE GOTHIC VAULT [CH. Ill Abbaye the dottcd Hncs show the… … Fig. 14. segmental, struck from a point below the springing, adevice no doubt to avoid a domical crown; and thesurfaces of the panels are very winding. In the vault of the Abbaye aux Dames at Caen CH. Ill] THE GOTHIC VAULT 43 this is avoided by not turning any vault from the Abbayeintermediate…
Architecture, Gothic
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
