Nisbet, Harry · London, Scott, Greenwood & son; New York, D. Van Nostrand co.; [etc., etc.] · leaf 30
18 GRAMMAE OF TEXTILE DESIGN. same sheds of warp. Figs. 9 to 12 are designs for this class of rib weaves containing two, three, four and six picks respectively, in each shed. Each design repeats on two warp ends, and such number of picks as are contained in two ribs, namely, four, six, eight and… … other weaves, in which several successive picks are inserted in the same shed, it is necessary to furnish a loom with a selvedge motion, to operate selvedge warp ends in a different order from .that of warp ends forming the body of the fabric, and thereby 1 T : I : 1 ■■■■■i PP^HHH i I i 1 1 i…
Textile design
Internet Archive · Claire T. Carney Library, University of Massachusetts Dartmouth · Public domain (published before 1931). Free to use for anything.
