United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 847
a supporting-loop for said member having aninclined supporting portion for shifting saidmember slightly backward relatively to thediaphragm when the reproducer is movedout of operative position; substantially asdescribed. In testimony whereof I have hereunto setmy hand in the presence of two… … C-B Tf2 JT ^ / J> jr
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 847](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten07unit-847-548.webp)
