United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 871
ATTORNEY COLUMBIA PLANOORAPH CO., WASHINGTON. D. C. A. C. DIEHL. SOUND BOX.APPLICATION FILED AUG. 31, 1910. 1,156,217. Patented Oct. 12,1915. 5 SHEETS-SHEET 3. 7A 76- … INVENTOR JUb&rJrC..Ztie/il. WITNESSES BY
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 871](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten15unit-871-465.webp)
