[Graphophone patents] (1878)
United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 683
![An illustration from [Graphophone patents], 1878, leaf 683](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten20unit-683-310.webp)
Attorneys C. W. EBELING.VARIABLE SPEED MECHANISM FOR SOUND AND PICTURE REPRODUCING MECHANISM. APPLICATION FILED OCT. 30, 1913. RENEWED JAN. 19, 1918. 1,261,796. Patented Apr. 9,1918. 5 SHEETS-SHEET 4-Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
