BBBB it So tti^ Fig. CXIX. The beauty of an ingrain carpet consists in its color combination. In hand- looms the common batten is used in connection widi a shuttle which is somewhat curved, a form most suitable to being thrown by the hand. The batten naturally falls towards the weaver by its own… … they are laid on the woven piece of carpet before the weaver, and he selects them as required. If a solid shuttle-race is connected to the batten, the warp-threads are pressed down upon it and the shuttle slides upon the ridge of the warp-threads. In this case the "fly-shuttle" is used, and also…
