The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 156

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 156
le line in 114. After this 113 is destroyed,made over again in 114, but so much smaller than before asthickness of the clay lining; when the new back-mould, 113, isplaced in contact with 112, it leaves the required space for the in-tended casting. This mode is only preferable to the first, when… … 114. andthe 152 CASTING AND FOUNDING. ed there will be a risk of irregularity of thickness, or even of holesin the casting. The third mode is to take a casting of 111 in plaster Of Paris ;when this is thoroughly dry it is oiled, and poured full of a cementof wax, grease, and red-ochre, which is…

Metal-work · Electrometallurgy · Metallurgy
