The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 206

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 206
s of a and c, by the fixed centre screw d ofthe lathe, so that a, 5, and c, revolve with the mandrel: and now bymeans of a burnisher e, which is rested against a pin in the latherest, as a fulcrum, and applied near the centre of the metal; and awooden stick /, held on the opposite side to support… … The mould a, is next replaced by g, Fig. 195, a plain cylindricalblock of the diameter of the intended aperture ; one of various formsof burnishers (h, i, some bent, others T form, and so on, the sur-faces of which are slightly greased,) are used together with the hookedstick or rubbery, first to…

Metal-work · Electrometallurgy · Metallurgy

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
