The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 177
J DETAILS.Plate XXXV. Fig. 1.—The pendant in the angle of the roof or pediment.Fig. 2. — Section of the same. Fig. 3. — Ornamented barge-board. From A to B, a section ofcornice and barge. 87 88 No. 51. … No. 51 gives a representation of a piggery, which should be raised upon alittle declination, so as to allow the drainage of the urine, and divided intosties of between six and seven feet in width and fourteen or fifteen feet long,the back part of which should be covered with a low roof, and…
Carpentry · Architecture
