The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 207

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 207
GROUND FLOOR FRAMING. Plate XLIII. This plate shows the frame for the ground floor of the Grecian house,with a proper arrangement of timbers, and their sizes marked, &c. 103 104 No. 70.

Carpentry · Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
