Palladio, Andrea, 1508-1580, Le Muet, Pierre, 1591-1669, Richards, Godfrey, Pope, William · London : Printed for A. Bettesworth & C. Hitch, and J. Osborn ... : S. Birt ... : and J. Hodges ... · leaf 210
l, and Upright Brick-WalU & 5. Braces. 6. Quarters. 7. Interdaces. , « 8. Prick-pofi, or Window-pofl. 9. Jaums or Door-poft. 1 o. King piece, or Joggle-piece. 11. Strutts. 12. Collar-beam, Strutt-beam, Wind-leam, or fop-beam. 13. Door-hand. 14. Principal Rafters. 15. Furrings, or Shreadings.… … 194- ®f -Archite&ur?. C H A P. XLVilL Dcjign of the Gabel-End or Roof B. LET the whole Breadth of the Gable-End or Roof A A be-20 Foot, divide the fame into four equal Parts, takethereof three for the Length of the Principal Rafter A B, andplacing that perpendicular from the Point C to the…
Architecture
