The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 209
GROUND FLOOR FRAMING. Plate XLIII. This plate shows the frame for the ground floor of the Grecian house,with a proper arrangement of timbers, and their sizes marked, &c. 103 104 No. 70. … No. 70 presents the ground-plan to foregoing front and end elevations,Nos. 68 and 69. Though the size of the main house is but thirty-five feet by forty-one feet,with an ell of twenty-eight feet by eighteen feet, for symmetry of form, size,and connection of apartments, and abundance and convenience…
Carpentry · Architecture
