The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 73
his plate, see Plate 8.The minute on this plate is TV of an inch ; and on Plate 8,Study and close examination will enable the student to understand thisorder without any further explanation. We do not intend to give a fulland minute representation of all the orders, for this work is designed,more… … No. 5, as above, represents a side elevation of the same house.The upper floor, as seen in No. 6, may be explained as follows : (n)stair-landing, (o, p, q, r,) bed-rooms, (p) store-closet, (s, t,) also for closets. No. 6.
Carpentry · Architecture
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
