Illinois Society of Architects · Chicago · leaf 336
the facilities for handling coaland ashes are apt to be cramped in the ex-treme, and the wise engineer or architect willsee that due consideration is given to thisbefore his plans proceed too far; otherwise.even though he avails himself of the aid ofelevating and conveying devices, he will failto… … Figure 1. Figure 1 is a typical modern arrangementwhere the boilers are on practically groundlevel and reasonahle space has been availa-ble. The pivoted or gravity bucket conveyoris almost uiversally used because of its sim-plicity and durability; its freedom fromnoise and vibration; and because…
