e work. Inorder to be of service these diagrams mustbe accurately drawn and amplified by detailswhere necessary. The importance of a plumbing plan care-fully laid out has unfortunately nut beenproperly recognized. At the present time tincost of material is such that the Architectwho is going to… … Flloh Tat Tyi girders, etc., proportioned to the loads theymust carry, and all this work carefully de-tailed—and still the plumbing work is veryrarely even laid out beyond a mere indica-tion of the. main run of soil or sewer lines—on the basement or foundation plan. Specifications very often…
