calculated stresses-and whose grip exceeds five diameters, shallhave their number increased 1% for each ad-ditional Vin inch in the rivet grip. Specialcare shall be used in heating and driving suchrivets. (c) Rivets shall be used for the connec-tions of main members carrying live loadswhich produce… … Mctioi„,lit;in and Eitel Bldg.;. (. W. \- (k-i. L. n<\v\), Architce; 7000 TONS McClintic-Marshall Companysteel structures First National Bank Building CHICAGO HO rivets. The finished shank shall be long-enough to provide full bearing, and washersused under the nuts to give full grip whenturned…
