ut. In judging the value of such projections itshould be borne In mind that In execution thehigher vertical faces of the composition will usually be much foreshortened to the ob-server and that there will be a consequentIncrease In the comparative value of neigh-boi Ing projections. A perusal of… … TV SCAN DOR.IC IONIC COK.INTHIAN Height of Plinth, Yi height of Pedestal. Height of Pedestal Base, % height of Ped-estal Plinth. Height of Pedestal Cap, % height of Pedes-tal Plinth. Projection of Cap and Plinth, y3 height ofPedestal Plinth. Projection of Corona over Die, % projectionof Pedestal…
