Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 139
Fig. 17.—Surplus metal removedby filing. Fig. 18.—Blank set forcutting. Fig. ig.—Gear in variousstages. For teeth coarser than five diametral pitch in cast iron, it is ad-visable to take a preliminary stocking cut, and in steel such a cutshould be taken in nearly all cases. With this system of…
