Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 458
Fig. 30.—Open eccentric rods. eccentric rods—the variation increasing as the rods are shortened.The proper radius of the link is the length of the eccentric rods plussuch distance as there may be between the geometrical link arc (thecurved center line of the link) and the eccentric-rod pins. With…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
