Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 47
Fig. 30 … Figs. 30 to 32. Fig. 32.-The double cone spindle bearing. Fig. 32 shows a construction by Mr. Dangerfield in which bothend thrusts are on the front bearing. The rear bearing is straight.iff is a split taper sleeve closed by the nut I and keyed to its bush Kby the pin /. In case of wear of the side…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
