Practical instructor and reference book for locomotive firemen and engineers: a practical treatise .. (1916)
Lockhart, Charles F. (Charles Fulton), b. 1872 · New York, The Norman W. Henley publishing co. · leaf 223
Fig. 65.—Release Position When Locomotive Brake is Released by-Independent Brake Valve, After an Automatic Application. 220 THE DISTRIBUTING VALVE the pressure chamber or brake pipe, or causing any move-ment of the equalizing portion. 606. To release the locomotive brakes independentlyafter an… … Fig. 66.—Quick Action Cylinder Cap for No. 6 Distributing Valve-. valve, it is necessary to hold the independent brake valvein full release position. This is occasioned by the main-taining feature which supplies air from the main reservoir QUICK ACTION CYLINDER CAP 221 to the application cylinder,…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
