Fig. 91 … Fig. 92 280 A HAND BOOK FOR MECHANICS Then 20° X 2i , 687 lb. The Windlass The windlass is a combination of the wheel and axlein which a crank answers the purpose of the wheel. The windlass consists of an axle A, B, and a crankC, D, E, Fig. 93, by means of which the axle A, B, isturned.
