itcan always be kept on the instrument, the prism-sheath beingturned out of the way; and with some practice will perform yeo-mans service. It consists of two prisms, inclined to one another,in a common setting. The rays (s) coming from the pencil take,after double reflection inside the prisms, a… … Fig. 16.—Two-prism Drawing Camera by Zeiss ; three-quarters natural size. anterior edge, visible through the opening in the setting, approxi-mately bisects the pupil of the emerging rays of the micro-scope, i.e., the bright circular disk which we notice when we lookperpendicularly into the…
