Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.' (1874)

Bourne, John · New York, D. Appleton · leaf 366

An illustration from Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.', 1874, leaf 366
es- 350 POWER AND PERFORMANCE OF ENGINES. sure on the piston 22*3 lbs. per square inch. The area of a cylin-der of 64 inches diameter is 3216*2 square inches, the double ofwhich (as there are two cylinders) is 6433*8 square inches, andas there 22*3 lbs. on each square inch, there will be a total…

Steam-engines
