Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.' (1874)

Bourne, John · New York, D. Appleton · leaf 442

An illustration from Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.', 1874, leaf 442
d being less than the area at a, the velocity will begreater; and the height of the water in the small tube d will notcome up to the level of a. At c, the velocity of the water beingvery great^ not only no height of column will be supported in thetube c there inserted, but the water will be sucked… … FRICTION OF THE BOTTOM OF VESSELS. 427

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
