Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.' (1874)

Bourne, John · New York, D. Appleton · leaf 460

An illustration from Handbook of the steam-engine. Containing all the rules required for the right construction and management of engines of every class, with the easy arithmetical solution of those rules. Constituting a key to the 'Catechism of the steam-engine.', 1874, leaf 460
Fig. 59. -C OTA N GEM … RESISTANCE FROM FRICTIONAL EDDIES. 44.5 face. The velocity with which the particles of water whirl in those ed-dies, bears some fixed proportion to that with which those particlesglide over the ships surface; hence the actual energy of the whirlingmotion impressed on a given mass of water at the…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
