A handbook on the teeth of gears, their curves, properties, and practical construction (1887)
Grant, George B. (George Barnard), 1849-1917 · [Boston] · leaf 21
mag = 90° — -^ in which s is the number of teeth in the smallest gear in the pair. If theangle is greater than this the motion will not be continuous, as each piniontooth will pass out of action before the next one is in position to act. INTERCHANGEABLE SETS. Any number of involute gears from base… … FIG. 17. CONSTRUCTION. 18
Gearing
