A handbook on the teeth of gears, their curves, properties, and practical construction (1887)
Grant, George B. (George Barnard), 1849-1917 · [Boston] · leaf 59
fthe cycloidal system is not by any means thegreatest objection to it in comparison withits simpler and superior rival. *The discovery of the law of internal interference, as far as it relates to cycloidal teeth, is generallycredited to Prof. C. W. MacCord ; but, in claiming that discovery, the… … Table for the Teeth of Gears. DiannetralPitch 4 5 6 7 8 10 12 14 16 20 24 28 32 36 40 48 CircularPitch .785 .628 .524 .448 .392 .314 .262.224 .196 .157 .130 .112 .098 .087 .078 .065 Thicknssof Toothat P. Line .393 .314 .262 .224 .196 .157 .131 .112 .098 .079 .065 .056 .049 ,043 .039 .038 for…
Gearing
