Grant, George B. (George Barnard), 1849-1917 · Boston, Grant gear works, incorporated · leaf 42
/ / Undercurved flanh» Fig, 55. … Secondary lines of action Fig\ 56, 40 Cycloidal htteryerence. 79.—INTERNAL INTERFEEENCE. If the secondary lines of action do notcome together the teeth will not touch eachother at all, but if that of the gear is smallerthan that of the pinion the teeth will crosseach other and interfere. The line…
Gearing
