A handbook on the teeth of gears, their curves, properties and practical construction (1885)
Grant, George B. (George Barnard), 1849-1917 · [Boston] · leaf 6
FIG. 3. THE EPICYCLOIDAL TOOTH. … FIG .4 WHOLE EPICYCLOIDAL TEETH. If a projection be formed on the frictionwheel fig. 4, the curved outline of whichis a whole epicycloid E, and a depressionbe formed in the wheel N having a wholehypocycloid H for its outline, then, if bothcurves have been formed by the samedescribing circle B, it…
Gearing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
