Handicraft for handy boys; practical plans for work and play, with many ideas for earning money (1911)
Hall, A. Neely (Albert Neely), b. 1883- · Boston, Lothrop, Lee & Shepard Co · leaf 350
the runners to the ends of the cleats,using three cleats for each sled and spacing them asshown in Fig. 378, and then screw the angle-braces tothe runners and to the cleats (Figs. 376 and 378). Cut 292 HANDICRAFT FOR HANDY BOYS The Sled Seats 22 inches long out of 10-inch boardsand screw them to… … W/AWV/M///////A 1 Cleats A ^ ft 1 Fig. 375Fig. 376Fig. 377Fig. 378Fig. 379Fig. 380Fig. 381 2-6 Fig. 375. Fig. 376. — Pattern for Runners. — Cross-section of Sled showing how Runners are Braced. — Iron Braces for bracing the Runners. — Longitudinal Section of Completed Bob-sled. — Blocks for…
Woodwork · Toys · Amusements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
