Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 86
Fig. 73.—Diagram of a multiple or parallel connection. When connected in this manner thevoltage of the battery is the same as that of a single cell, but the current is equal to theamperage of a single cell multiplied by the number of cells. Thus with 1Y^ volt 15 amperedry cells, the combination or… … Fig. 74—Diagram of a series multiple connection. Two sets of cells are connected in seriesand the two batteries thus formed, connected in parallel. The pressure equals the voltageof one cell, multiplied by the number of cells in one battery, and the amperage, that ofone cell multiplied by the…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
