Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 160

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 160 — the fixed relation existing between the direction of thecurrent in a conductor and the magnitude and the direction of theresulting magnetic field. This relation is shown graphically inFig. L A circular conductor ABC is connected with a battery ofthree cells E connected together in series and… … Fig. 1. Magnetic Lines of Force around Conductor plete curves, which are circular in the case of a straight wireremoved some distance from other current-carrying wires. In theillustration the surrounding magnetic lines are shown in circleshaving directions indicated by the arrowheads. Right-Hand…

Electric motors · Electric transformers · Electromagnets · Induction coils

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
