Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 43
GALVANOMETER r I SHUNT -i I Fig. 537.—EHagrajn showing method of connecting galvanometer shunt. By the use of a shuntthe range of measurement of a galvanometer can be greatly increased. … Fig. 538.—Diagram of a form of universal shunt box for use with galvanometers of widelydifferent resistances. The galvanometer, as indicated at G. is connected across the endsof a series of resistances AB. The main wires are connected, one to end A of the series andthe other to a travelling point…
Electrical engineering
