Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 25
ynamo winding of the dyna-motor and is supi^lying current to the upper or larger load, and the lowercommutator is connected to the motor winding of the dynamotor and istaking current from the lightly loaded side. Motor-Dynamo or Balancing Set.—A balancing set orbalancer consists of a motor… … Fig. 800.—Holzer-Cabot type M motor-dynamo set. This combination is known as a booster,and is used to raise or lower the voltage on feeders. The motor is series wound and con-nected in series with one leg of the feeder. Thus, the voltage which the booster will addto the line will be directly in…
