Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 230
ibuted or Multi-Coil Windings.—Instead of winding an armature so it will occupy only one slot per ph pole, it may be spread out so as to fill several slots per phase per pole.This arrangement is called a distributed winding. To illustrate, fig. 1,496 represents a coil of say fifteen turns.… … PARTIALLY DISTRIBUTED COli. FULLY DISTRIBUTED COIL Pigs. 1 3 —Alternator coils, showing difference between the concentrated, partially distributed, and fully distributed forms. Fig > a concentrated coil in which r.e wire is wound in one large coil; in the partially distributed type fig. 1.497,…
Electrical engineering
