A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 158
re, A is the fire box with grate R and furnace door § 403-] STEAM-GENERATING APPARATUS. H5 T; BB is the water space with the heating- pipes, CD thesmoke box, and £ the chimney. The remaining parts ofthe figure are explained further on. In other tubular boil-ers—for instance, those of Zambeaux—the… … space is enclosed by water, and the products of combustiontraverse a longer distance ABCDE before entering thechimney at F. These boilers are very economical, butthey can only be employed for low pressures on accountof their sharp corners and angles. These marine boilershave been recently much…
