ished from a poly-phase transformer, or combination in one unit of several onephase transformers with separate electric circuits but having cer-tain magnetic circuits in common. In polyphase transformers TRANSFORMERS 1,393 there are two or more magnetic circuits through the core, andthe fluxes in… … F:GS. 1.934 and 1.935.—Top view showing core and coils in place, and view of coils of Westing-house distributing transformer. The coils are wound from round wire in the smallersizes of transformers and from strap copper in the larger sizes. Strap wound coils allowa greater current carrying…
