Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 340

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 340
hange theratio of transformation, and obtain ratios of 20 :1,19 :1, IS : 1,10:1,9.5:1, 9:1,5:1, and 4.5:1, according to the connections of theprimary and the secondary sections, whether in series or in parallel.The advantage of these ten per cent taps is that it permits atransformer to be used near… … Fig. 268. Top View of Fort Wayne Transformer with CoverRemoved Showing Arrangement of Lead Wires Figs. 2G9 to 271 show constructive details peculiar to very largeshell-type transformers which are usually of the water-cooled type.Fig. 2G9 represents a General Electric transformer with its…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
