Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 43
each phase, », adjacent coils being joinednd clockwise, and the ALTERNATING CURRENT MOTORS 1,301 As the cycle continues, however, the strength of a will diminishand that of b increase, thus shifting the induced pole toward C,until b attains its maximum and a falls to its minimum at 90°or the end of… … Pig. 1,663.—Diagram of two phase, eight pole field winding. The winding is divided into16 groups (equal to the product of the number of poles multiplied by the number of phases).Each group such as at A comprises a number of coils in series, each coil being located in aseparate pair of slots, the…
Electrical engineering
