Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 171
ads are disconnected and the brushesraised. ALTERNATORS 1,159 phase coil. It is provided with three collector rings; two forthe single phase coil, and one for the free end of the teaser coil.By this arrangement ordinary single phase incandescentlighting can be accomplished by means of a single pair… … Fig. 1.410.—Diagram showing connections of General Electric monocyclic alternator. Thesolid lines show standard connections for counter-clockwise rotation; the broken linesshow connection changed for clockwise rotation. to the point at which the motor is located, and by the use of twosuitably…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
