Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 83
Tig. 1S29.—General Electric single phase induction motor. It is suitable for constant speedse vice where full load torque at starting does not exceed 140 per cent., and in general isadapted to drive all geared and belted machinery requiring constant speed with light ormoderate starting torque.… … MOTOR FIELD WINDINGSAUXILIARY COILS MAIN COILS ALTERNATOR Ftg. 1.830.—Simplified diagram showing the principle of phase splitting for starting singlephase induction motors. By the use of an auxiliary set of coils connected in parallel withthe main coils and having in series a resistance or…
Electrical engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
