Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 233
*T\1 Fig. 2,459.—General Electric line drop compensator. It has two dial switches with manytaps to the resistance and reactance in the box so that it can be adjusted to compen-sate accurately for lir.e losses with loads of varying power factor. Dial R changes re-sistance, and dial X, reactance. … FlG. 2,400. General Electric line drop compensator. This compensator contains besides resistance and inductance, a current transformer, the secondary of the transformer beingconnected in series with the resistance and inductance; the primary of the containedcurrent transformer is connected to an…
Electrical engineering
