C N Fig. 2,5.58.—-Faraday disc, or mercury motor ampere hour meter; view showing electric andmagnetic circuits. essentially of a copper disc floated in mercury between thepoles of a magnet and provided with leads to and from themercury at diametrically opposite points. The theoreticalrelations of… … contact C, passes throughthe comparatively highresistance mercury H tothe edge of the low re-sistance copper disc Dacross the disc to themercury H and out ofcontact C. The mag-netic flux cuts across thedisc on each side fromN to S, making a com-plete circuit through Mand M. -The relativedirections…
