The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 98
BLE ECCEXTKICS 87 trie in the fall gear forward. About F as a centre strike acircle for the eccentric enclosing the pin A by a distancesufficient to give ample strength to the eccentric pulley.The distance C F will then equal the J travel of the valve,with which radius the travel circle F B may be… … lh3 above cut illustrates another modification of theadjustable eccentric. In this device, the collar H is madelarger than the eccentric pulley, and keyed fast to theshaft. The pulley E is secured by the bolt A, and anytendency to its rotation prevented by means of a feather onthe back, which fits…
Steam-engines
