Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 369
TERHIMAL HUNT COILDASH POT1PLUHGER^WALKING BEAMV-GUTOUT RMINALS ADJUSTINGWEIGHT CLUTCHRQD RESISTANCE CLUTCH UPPER CARBON LOWER CARBQM INNER GLOBE INNER GLOBE STIRRUP SERIESCOILS WALK!BEAM CLUTCHROD … SHUNTCOILS DASH POT ADJUSTINGWEIGHT- TALKINGBEAM Figs. 3,379 and 3,380.—Westinghouse series parallel circuit differential control direct currentenclosed arc lamp. The U shaped armature for each set of coil is made from one pieceof round iron bent into the form shown. The shell of the dash pot is…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
