lates. brake handle is multiplied in amount to the desired direction,and applied to the brake shoes which press against the wheelsof the car. Fig. 3,660 shows a typical hand brake system. ELECTRIC RAILWAYS 2,601 Ques. How do air brakes operate? Ans. By power derived from compressed air and… … j?ig. 3,667.—Geared brake. This apparatus has a pinion A, on the lower end of the brakestaff, which engages a gear B, made in one piece with a double sprocket wheel. The twochain loops running through these sprocket wheels engage two hooks formed on the endof the brake rod, or two separate brake…
