Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 176
isfactory workingof the chain. The cut illustrates single and double reduction chain drive. For singlereduction the motor would be located at A, and for double reduction, at B. Ques. What is the advantage of the chain drive? Ans. The greater portion of the weight of the drive mechan-ism is… … Figs. 4,074 to 4,077.—Details of Woods electric vehicle construction. Fig. 4,074, motorsuspension showing detail of the hangers between which the motor is suspended; fig.4,075, radius rod connection, showing phantom view of radius rod and how attachedto rear axle housing. Also mounting of rear…
Electrical engineering
