L^S^ FiG. 3,790.—Virtual focus in double convex lens. In the figure, L is the position of the luminoussource between the principal focus and the lens; F is the principal focus, and L, the virtualfocus corresponding to the position L of the luminous source. C-t{ … Fig. 3,791.—Foci of convex mirrors. This type of mirror has only virtual foci. Let SI, and TKbe rays parallel to the principal axis of a convex mirror. These rays, after reflection, takethe diverging directions IM, KH, which, when continued, meet at a point F, which is theprincipal virtual focus.…
